six safety notes! How to maintain and operate cnc engraver co2 laser machine

Views:8     Author:Site Editor     Publish Time: 2017-07-11      Origin:Site

six safety notes! How to maintain and operate cnc engraver co2 laser machine

1.good grounding of laser engraving machine

Laser tube power,co2 cnc laser equipment bed must have a good grounding protection,ground line should be less than 4Ω dedicated line.The necessity of good grounding is:

(1) to ensure that the laser tube power work properly

(2) to extend the lifetime of laser tube

(3) to prevent external interference caused by machine vibration

(4) to prevent high-voltage discharge caused by circuit damage

2.smooth cooling-water flowing of cnc engraving co2 laser

Whether it is to use tap water or water pump, you must keep the water flow smoothly.Cooling water is to take away the heat generated by the laser tube,the higher the water temperature,the lower the light output power (15-20 ℃ water temperature is preferred).

3.keep clean and good exhaust of laser engraver cnc machine

The machine guide rail is a high-precision core components,it must be wiped after the working finished.The bearings should be regularly lubricated,so as to make the driver working flexibly, extending the lifetime of co2 laser cnc engraver machine.

4.operating temperature and humidity of cnc equipment co2 laser engraver

The operating temperature should be within 5-35℃.It is important to notice that if cnc engraving co2 laser used in the freezing conditions,the water inside the laser tube must be poured out.And the co2 laser engraving machine must be warmed up for at least 5 minutes.

5.away from high power and strong vibration equipments

The large amounts of electricity interference sometimes results in machine failure,although low rates,but still need to avoid.Therefore,the cnc co2 laser machine should be away from such as large welding machine,giant power mixer and large power transmission equipment.

6.lightning protection of cnc co2 laser engraver

The "good grounding" in this section one can also contribute to good lightning protection.

Special recommendations: In areas where the network is unstable (such as voltage fluctuation more than 5%),please install a capacity of at least 3000W power supply,to prevent burning of circuit and computer by sudden fluctuations.

Thanks for your time.Hope this is helpful for you.
