How to set the most reasonable cnc wood carving router spindle rotating speed?

Views:2     Author:Site Editor     Publish Time: 2017-08-01      Origin:Site

How to set the most reasonable cnc wood carving router spindle rotating speed?

How to set the most reasonable cnc wood carving router spindle rotating speed?


Under normal conditions, the most essential parameter which affect the service life of wood carving cnc router engraving tools is the spindle speed. Under the same situation, the slower the cnc wood engraver spindle speed is, the longer life the cnc wood engraver router will have. Therefore, in order to prolong the life of cnc wood carving router’s tool life, users wish to set a relative low spindle speed. But we should know that the there is no way for cnc engraving machine’ s spindle motor speed reducing without limitation. When wood engraving cnc router’s spindle motor is at a much lower speed, the milling degree will become bigger producing much pressure for cnc engraving machine’ s tools withe the same feeding speed. Therefore, there is a reasonable speed range when cnc wood engraver router processes the some kind of material.


1.Cutting speed


(1)Organic glass( acrylic)

Thickness    Speed      Rotating speed

20mm        5-6           20000-22000

15mm        6-7           19000-21000

10mm        8-9           18000-20000

5mm        10-12         18000-20000

3mm        10-14         16000-18000


(2) PVC( cutting anticlockwise)

Thickness   Speed       Rotating speed

20mm       8-12          18000-20000

15mm      10-14         16000-18000

10mm      15-20         16000-18000


(3)Lotus board (Cutting anticlockwise)

Thickness    Speed      Rotating speed

20mm       15-20        18000-19000

15mm       20-25        16000-18000

10mm       20-25        16000-18000


(4)MDF (single edge tool cutting)

Thickness    Speed      Rotating speed

18mm        6-8           18000-20000

15mm        8-10         18000-20000

10mm        10-14       17000-19000


(5)Double color plate

Thickness    Speed      Rotating speed

1.5mm       12-20        12000-14000


2 Engraving speed


(1)Double color plate engraving plate

Nameplates

Thickness     Rotating speed

18-24           12000-14000


Big doorplate

Thickness     Rotating speed

25-35           12000-14000


(2)Engraving 3D words with a big large angle

Thickness     Rotating speed

1-18            16000-18000


Hope this article will help you. If you have any questions about wood carving cnc router price and qualities, please contact us as soon as possible. Jinan Dekcel Cnc Euipment Co., Ltd will always be there for you.
