The features of Dekcel oscillating knife cutting machine for gasket

Views:14     Author:Site Editor     Publish Time: 2017-08-12      Origin:Site

The features of Dekcel oscillating knife cutting machine for gasket

Dekcel oscillating knife cutting machine for gasket


Jinan dekcel cnc company specialize in producing the oscillating knife cutting machine for gasket.  In order to pay back the kindness and trust of customers, Dekcel will share the features and specifications of the oscillating knife cutting gasket machine in the following passage, which includes the cutting materials, the products overview and the product specifications.

gasket socilaltion knife cutting machine.jpg

Cutting material and thickness:

Leather, PU, EVA, XPE, corrugated cardboard, PVC, sponge, self-adhesive, composite materials etc. And the thickness is less than 15mm material.


Product overview:

Ultra high frequency oscillation knife cutting machine for leather PE foam

The leather, paper and plastic and other flexible materials can be die cutting without die board cutting machine, which can save a lot of manpower and the cost of die cutting machine.


Dekcel cnc oscillation knife cutting machine for gasket replaces the traditional handmade paper design and proofing, shortening the corresponding development time.  In order to meed the customer’s demand of small batch, multi-type and multi-order, Dekcel cnc company crates a set of standard and practical solutions for every customer.


Product specification:


Machine model: Dek-1625

Features: computer operation and oscillation knife cutting machine for paper board could work at the same time and achieve rapid data transmission, which can be used continuously

Cutting speed: 800mm/s to 1500mm/s

Cutting materials: leather, PU, EVA, XPE, corrugated cardboard, PVC, sponge, self-adhesive, composite materials

Motor: imported servo motor

Vibration frequency: vibration motor 180 RPM

Effective cutting size: 2500mm * 1600mm

Material fixation method: intelligent vacuum adsorption

Mechanical resolution: 0.07mm

Software resolution: 0.01mm

Transmission interface: standard parallel port, serial port, network port

Transmission material: Taiwan linear guide rail, imported synchronous belt, Identification Format DXF, PLT

NC panel: LCD display and touch button

Main work voltage: AC 220V + 22V

Main operating frequency: 50 + 1Hz, 60 + 1Hz

Working voltage of air pump: AC 380V + 38V

Air pump power: 9kw


Hope this article will help you. If you have any questions about wood carving cnc router price and qualities, please contact us as soon as possible. Jinan Dekcel Cnc Euipment Co., Ltd will always be there for you.
