Dek-1390 Reci 100w co2 cnc laser cutter engraver for acrylic

Cnc co2 laser cutter and engraver is a machine perfectly designed for cutting and engraving acrylic with depth of 0-30mm, with less waste,no burning edges, bright color.
If you want to know more about laser cutter or laser engraver,please feel free to ask us.
Availability:
Quantity:
  • Dekcel CNC

 Dek-1390cnc co2 laser machine,with double function of high-speed engraving and cutting,can be equipped with double heads as required.Cnc Co2 laser cutter or engraver can realize stable operation,less cutting waste,low cost,automatically engraving depth adjustment,no burs on cutting edge,no polishing.

Technical paremeters:

The laser power: 40w,60w,80w,100w,130W,150w,260w

The engraving speed: 0-60000mm/min

The cutting speed: 0-50000mm/min

The cutting thickness 0-25mm organic glass

The minimum Chinese characters 2*2mm;letters 1*1mm

Supporting Files: AI DST PLT BMP DXF

The resolution:<0.01mm

The power supply: AC220V

The positioning accuracy:<0.01mm

The total power:<1000W

The humidity of 5%-95%

cnc laser cutter and engraver for acrylic.jpg

Detailed description of cnc engraver co2 laser :

1.The lifting platform can be added as required.The worktable has honeycomb table or blade table for you to choose.

2.Double rail design,with high precision,difficult to wear and tear.

3.Mechanical structure design with high strength,high stability,making the whole process steady.

4.Adopt imported Singapore focusing mirror and reflect lens.The spot is thinner and the cutting power is stronger.

5.The perfect dustproof and antipollution design greatly improves the stability of the whole machine.


Suitable materials of laser cutter and engraver:

Double color plate,organic glass,wood board,paper,leather,marble carving,granite engraving, fabric,pvc, eva,foam, rubber and some metal materials such as cutting stainless steel,carbon steel etc.
